2020 Fishin' Barge 24 DLX

2020

FISHIN' BARGE® 24 DLX

w/ 115 ELPT FourStroke Command Thrust Mercury® FourStroke
Price Excludes Optional Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
Base Price
$30595
USD

Overview

The FISHIN’ BARGE® 24 DLX delivers all the room you and your crew (a total of 12 people!) need to make a boatload of memories together on the water.

Start by taking advantage of this model’s many, many fishing features. Four fishing chairs (two at the bow, two aft) provide comfortable spots to cast from, or relax while you wait for a bite. Caught a keeper? The bow and stern livewells are both aerated to keep your keepers healthy. The aft one also has a removable bait bucket for minnows! There are even rod storage spots throughout the entire boat, including a new starboard locker right behind the helm.

Speaking of the helm, it provides cooler storage, as well as a reclining helm seat. Other seating is in the form of the forward-helm couch and aft L-lounge, both with our STOW MORE™ seat storage system to keep your gear handy and ready to go.

Key Features

Bimini top

The color-keyed top extends via the QUICKLIFT deployment system to a full 11'.

Console storage

The compartment under the console is perfect for stowing a cooler out of the sun to keep your drinks colder longer.

Entry gates

Whether fishing, relaxing or cruising, you'll enjoy peace of mind with little crewmembers thanks to the inward-swinging gates.


Videos


Specifications

Length 7.98 m 26' 2''
Deck length 7.34 m 24' 1''
Deck Width 2.59 m 8' 6''
Max. Recommended HP 150 HP
Fuel Capacity 121.5 L 32.1 gal.
Pontoon log length 7.42 m 24' 4''
Pontoon log diameter 60.96 cm 24''
Pontoon log material 0.080 5052 marine alloy
Max. Person Capacity 12 persons
Max. person weight 771.11 kg 1700 lbs.
Max. person, motor & gear weight 1088.62 kg 2400 lbs.
Interior depth 60.96 cm 24''
Average dry weight 987.02 kg 2176 lbs.
Average package weight 1929.13 kg 4253 lbs.
Package height 2.67 m 8' 9''
Package width 2.59 m 8' 6''
Towing length 10.46 m 34' 4''
Storage Length 10.46 m 34' 4''

Motor Options

AVAILABLE MOTOR ESTIMATED SPEEDS PACKAGE PRICE VIEW PRICE W/ PREP & FREIGHT
Mercury® FourStroke
9.9 ELPT FourStroke Command Thrust ProKicker -
$22975

USD
Select Dealer
25 ELPT FourStroke -
$24795

USD
Select Dealer
115 ELPT FourStroke Command Thrust -
$30595

USD
Select Dealer
150 L FourStroke -
$32995

USD
Select Dealer
Mercury® Pro XS®
115 ELPT Pro XS® FourStroke Command Thrust -
$30955

USD
Select Dealer

Features

Comfort, Convenience & Peace of Mind
  • 10+LIFE™ Limited Lifetime Warranty
  • NMMA® certified
  • NEW 11' (3.35 m) color-keyed Bimini top w/LED courtesy lights, protective boot & accepts optional drop-down changing curtain
  • NEW Bazooka® Party Bar stereo & speakers in the Bimini top
  • Front zipper on Bimini top to join optional forward Bimini together
  • QUICKLIFT® Bimini top deployment system, allowing 1 person to effortlessly extend the canopy alone
  • Storage pockets in Bimini top
  • Nylon gate latches & heavy-duty hinges that open inward
  • Port & starboard LED navigation lights
  • Bimini-mounted anchor/navigation light
  • 4 mooring cleats
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn
Livewell Systems
  • NEW bow port 16-gal. (60.57 L) rotomolded & aerated livewell w/shutoff valve & composite lid w/ruler
  • Aft port 16-gal. (60.57 L) aerated livewell w/removable bait bucket & shutoff valve
Console
  • Deluxe soft-touch sport steering wheel
  • 4:2 ratio no-feedback steering for responsive, easy turning
  • Wraparound sport console shroud & tinted, removable windscreen
  • Below-console cooler/storage space w/door & integrated pouch
  • Small items tray
  • Drink holders
  • Built-in footrest w/non-skid pad
  • Bluetooth®-capable stereo interface for Bazooka® Party Bar
  • Tachometer, trim meter/speedometer & fuel & hour gauges
  • Lighted rocker switches
  • Ergonomically positioned Mercury® binnacle control box w/trim
  • 12V outlet
  • NEW darker console color
Interior
  • STOW MORE™ system features an added compartment in the seat back for increased storage
  • NEW larger bow port rotomolded box w/livewell, ruler, drink holders & lid
  • NEW larger bow starboard rotomolded box w/storage, ruler, drink holders & lid w/room for 24V total battery capacity
  • Clam-shell fishing chairs constructed w/all-composite seat frames w/heavy-duty 2-3/8" (6 cm) diameter pedestals
  • Bow & aft fishing positions w/4 removable folding fishing chairs
  • Forward-console couch w/STOW MORE™ system & underseat storage
  • Aft L-lounge w/STOW MORE™ system, underseat storage & lockable storage compartment
  • Rear-facing tackle storage in aft L-lounge
  • NEW molded aft starboard lockable rod box for 6 rods to 7' 6" (2.29 m) w/lid, rod tube holders & organizer
  • High-back swiveling helm bucket seat, reclining & w/self-leveling arms
  • Fore & aft vertical rod holders
  • Woven 16-oz. (.45 kg) marine-grade flooring throughout
  • NEW marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
  • Movable drink holder/armrest
  • Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
  • Port wheelchair-access gate
  • 4-step folding boarding ladder w/grab rails
Performance
  • Nose cone & motor pod wave/spray deflectors for a drier ride
  • Factory-matched aluminum propeller
Construction & Exterior
  • Color: Black Metallic or Copper Red fencing
  • NEW exterior styling
  • Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
  • Rotomolded couches & backs for furniture w/NEW Diamante Pepper accent
  • Fishing seats w/NEW Diamante Pepper accent
  • Heavy-duty bow U-channel reinforcement behind deck trim
  • 24" (60.96 cm) diameter high-buoyancy multichambered pontoons w/internal bracing for additional strength
  • 1-piece full-length M-bracket deck supports
  • RAIL-LOCK® system for mounting optional tops & optional mooring cover
  • NEW protective exoskeleton rail & panel system for durability & a quieter ride
  • High-sheen fence finish for long-lasting good looks
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/decorative styling
  • Extruded anodized aluminum deck edging w/polished aft corner covers
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • Stainless or coated corrosion-resistant fasteners
  • 7-ply pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
  • Elevated fence panels for deck drainage & ventilation
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Box-beam all-aluminum transom for strength & longevity
  • Rear boarding platform
Electrical
  • Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
  • Interior courtesy lighting

Options
