2019 Party Barge 20 DLX

2019

PARTY BARGE® 20 DLX

w/ 40 ELPT FourStroke Command Thrust Mercury® FourStroke
Price Excludes Optional Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
Base Price
$19795
USD

Overview

At 21’ 11” long and 8’ 6” wide, the PARTY BARGE® 20 DLX is right-sized for towing to and from the water, but still provides plenty of room and features for a crew of 10.

Onboard this stable party platform, you’ll first and foremost find that comfort is kind, with a new helm seat for the driver and three lounges for the crew. Plus, each lounge features spacious storage, including the patent-pending STOW MORE™ seat-back compartments. Of course, that’s not all. A removable table, stereo, full-width swim deck with ladder and QUICKLIFT® Bimini top round out this fun package.

The PARTY BARGE 20 DLX is right-sized and right-featured for your fun.

Videos


Specifications

Length 6.68 m 21' 11''
Deck length 6.05 m 19' 10''
Deck Width 2.59 m 8' 6''
Max. Recommended HP 90 HP
Fuel Capacity 121.5 L 32.1 gal.
Pontoon log length 6.2 m 20' 4''
Pontoon log diameter 60.96 cm 24''
Pontoon log material 0.080 5052 marine alloy
Max. Person Capacity 10 persons
Max. person weight 621.42 kg 1370 lbs.
Max. person, motor & gear weight 861.83 kg 1900 lbs.
Interior depth 66.04 cm 26''
Average dry weight 768.84 kg 1695 lbs.
Average package weight 1523.16 kg 3358 lbs.
Package height 2.67 m 8' 9''
Package width 2.59 m 8' 6''
Towing length 9.19 m 30' 2''
Storage Length 9.19 m 30' 2''

Motor Options

AVAILABLE MOTOR ESTIMATED SPEEDS PACKAGE PRICE VIEW PRICE W/ PREP & FREIGHT
Mercury® FourStroke
9.9 ELPT FourStroke Command Thrust ProKicker -
$16275

USD
Select Dealer
20 ELPT FourStroke -
$17155

USD
Select Dealer
40 ELPT FourStroke Command Thrust 14-17 mph
$19795

USD
Select Dealer
60 ELPT FourStroke Command Thrust 18-23 mph
$20795

USD
Select Dealer
90 ELPT FourStroke Command Thrust 23-29 mph
$22895

USD
Select Dealer

Features

Comfort, Convenience & Peace of Mind
  • 10+LIFE™ warranty
  • NMMA® certified
  • 7' (2.13 m) color-keyed Bimini top w/LED courtesy lights & protective boot
  • NEW front zipper on Bimini top to join optional forward Bimini together
  • Exclusive QUICKLIFT® Bimini top deployment system, allowing 1 person to effortlessly extend the canopy alone
  • Storage pockets in Bimini top
  • Adjustable nylon pull-tight Bimini straps for quick adjustment & reduced vibration
  • NEW nylon gate latches & heavy-duty hinges that open inward
  • Port & starboard LED navigation lights
  • Bimini-mounted anchor/navigation light
  • 4 NEW folding mooring cleats
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn
Console
  • Deluxe soft-touch sport steering wheel
  • 4:2 ratio no-feedback steering for responsive, easy turning
  • Wraparound sport shroud & tinted windscreen
  • Below-console cooler/storage space
  • Small items tray
  • Drink holders
  • Built-in footrest w/non-skid pad
  • AM/FM Bluetooth®-capable stereo w/4 directional speakers
  • Illuminated tachometer, trim & fuel gauges
  • Lighted rocker switches
  • Ergonomically positioned Mercury® binnacle control box w/trim
  • 12V outlet
Interior
  • Bow port & starboard couches w/STOW MORE™ system & underseat storage
  • Aft L-lounge w/STOW MORE™ system, underseat storage & lockable storage compartment
  • NEW high-back swiveling helm bucket seat, reclining & w/self-leveling arms
  • Pop-up changing room
  • Full-width aft swim deck
  • Padded woven vinyl floor covering
  • Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
  • 2 movable drink holders/armrests
  • NEW removable table w/padded insert, 4 molded-in drink holders & 1 pedestal base location
  • Port wheelchair-access gate
  • 4-step folding boarding ladder w/grab rails
Performance
  • Nose cone & motor pod wave/spray deflectors for a drier ride
  • Factory-matched aluminum propeller
Construction & Exterior
  • Color: Charcoal Metallic or NEW Indigo Blue fencing
  • NEW interior styling
  • Rotomolded furniture backs & bases for resistance to the elements
  • Heavy-duty bow U-channel reinforcement behind deck trim
  • 24" (60.96 cm) diameter high-buoyancy multichambered pontoons w/internal bracing for additional strength
  • 1-piece full-length M-bracket deck supports
  • RAIL-LOCK® system for mounting optional tops & optional mooring cover
  • Protective exoskeleton rail & panel system for durability & a quieter ride
  • High-sheen fence finish for long-lasting good looks
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/decorative styling
  • Reinforced bow structure
  • Extruded anodized aluminum deck edging w/polished aft corner covers
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • Stainless or coated corrosion-resistant fasteners
  • 7-ply pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
  • Elevated fence panels for deck drainage & ventilation
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Box-beam all-aluminum transom for strength & longevity
Electrical
  • Easy-access marine-grade automotive-style fuse panel w/NEW latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
  • Interior courtesy lighting

Options
