2020 Party Barge 22 DLX

2020

PARTY BARGE® 22 DLX

w/ 60 ELPT FourStroke Command Thrust Mercury® FourStroke
Price Excludes Optional Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
Base Price
$25395
USD

Overview

The PARTY BARGE® 22 DLX takes full advantage of its 22’ 1” by 8’ 6” deck to provide you and your guests a ton of comfort and convenience features you’ll enjoy for years to come.

Onboard, you’ll find four extremely spacious lounges, each loaded with our STOW MORE™ seat storage system. This system includes rotomolded underseat storage AND seat-back compartments that can be accessed without even standing up! It builds on that comfort with a new 11’ QUICKLIFT® Bimini top, new Bazooka® sound system and more!

Like we said, everything you and 10 others need to get on the water and making memories together!

Key Features

Interior lighting

In addition to the Bazooka® color-changing LEDs, there are interior lights throughout to keep the party going after dark.

STOW MORE® storage

The seat-back compartments can even be accessed while sitting down!

Cleats

Flip up the cleats for mooring, or flip them down to avoid stubbing a toe while doing a canonball.


Videos


Specifications

Length 7.37 m 24' 2''
Deck length 6.73 m 22' 1''
Deck Width 2.59 m 8' 6''
Max. Recommended HP 150 HP
Fuel Capacity 121.5 L 32.1 gal.
Pontoon log length 6.78 m 22' 3''
Pontoon log diameter 60.96 cm 24''
Pontoon log material 0.080 5052 marine alloy
Max. Person Capacity 11 persons
Max. person weight 680.39 kg 1500 lbs.
Max. person, motor & gear weight 997.9 kg 2200 lbs.
Interior depth 66.04 cm 26''
Average dry weight 943.02 kg 2079 lbs.
Average package weight 1774.91 kg 3913 lbs.
Package height 2.69 m 8' 10''
Package width 2.59 m 8' 6''
Towing length 9.86 m 32' 4''
Storage Length 9.86 m 32' 4''

Motor Options

AVAILABLE MOTOR ESTIMATED SPEEDS PACKAGE PRICE VIEW PRICE W/ PREP & FREIGHT
Mercury® FourStroke
9.9 ELPT FourStroke Command Thrust ProKicker -
$20875

USD
Select Dealer
25 ELPT FourStroke -
$22695

USD
Select Dealer
60 ELPT FourStroke Command Thrust -
$25395

USD
Select Dealer
90 ELPT FourStroke Command Thrust 23-29 mph
$27495

USD
Select Dealer
115 ELPT FourStroke Command Thrust 21-29 mph
$28495

USD
Select Dealer
150 L FourStroke 29-38 mph
$30895

USD
Select Dealer
Mercury® Pro XS®
115 ELPT Pro XS® FourStroke Command Thrust -
$28855

USD
Select Dealer

Features

Comfort, Convenience & Peace of Mind
  • 10+LIFE™ Limited Lifetime Warranty
  • NMMA® certified
  • NEW 11' (3.35 m) color-keyed Bimini top w/LED courtesy lights, protective boot & accepts optional drop-down changing curtain
  • NEW Bazooka® Party Bar stereo & speakers in the Bimini top
  • Front zipper on Bimini top to join optional forward Bimini together
  • QUICKLIFT® Bimini top deployment system, allowing 1 person to effortlessly extend the canopy alone
  • Storage pockets in Bimini top
  • Nylon gate latches & heavy-duty hinges that open inward
  • Port & starboard LED navigation lights
  • Bimini-mounted anchor/navigation light
  • 4 folding mooring cleats
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn
Console
  • Deluxe soft-touch sport steering wheel
  • 4:2 ratio no-feedback steering for responsive, easy turning
  • Wraparound sport shroud & tinted, removable windscreen
  • Below-console cooler/storage space w/door & integrated pouch
  • Small items tray
  • Drink holders
  • Built-in footrest w/non-skid pad
  • Bluetooth®-capable stereo interface for Bazooka® Party Bar
  • Tachometer, trim meter/speedometer & fuel & hour gauges
  • Lighted rocker switches
  • Ergonomically positioned Mercury® binnacle control box w/trim
  • 12V outlet
  • NEW darker console color
Interior
  • STOW MORE™ system features an added compartment in the seat back for increased storage
  • Bow port & starboard couches w/STOW MORE™ system & underseat storage
  • Aft port couch w/STOW MORE™ system & underseat storage
  • Aft starboard couch w/STOW MORE™ system & lockable underseat storage
  • High-back swiveling helm bucket seat, reclining & w/self-leveling arms
  • Full-width aft swim deck
  • Woven 16-oz. (.45 kg) marine-grade flooring throughout
  • NEW marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
  • 2 movable drink holders/armrests
  • Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
  • Port wheelchair-access gate
  • 4-step folding boarding ladder w/grab rails
Performance
  • Nose cone & motor pod wave/spray deflectors for a drier ride
  • Factory-matched aluminum propeller
Construction & Exterior
  • Color: Black Metallic or Caribou Metallic fencing
  • NEW exterior styling
  • Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
  • Heavy-duty bow U-channel reinforcement behind deck trim
  • 24" (60.96 cm) diameter high-buoyancy multichambered pontoons w/internal bracing for additional strength
  • 1-piece full-length M-bracket deck supports
  • RAIL-LOCK® system for mounting optional tops & optional mooring cover
  • NEW protective exoskeleton rail & panel system for durability & a quieter ride
  • High-sheen fence finish for long-lasting good looks
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/NEW decorative styling & taller mid-rail fencing height
  • Reinforced bow structure
  • Extruded anodized aluminum deck edging w/polished aft corner covers
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • Stainless or coated corrosion-resistant fasteners
  • 7-ply pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
  • Elevated fence panels for deck drainage & ventilation
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Box-beam all-aluminum transom for strength & longevity
Electrical
  • Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
  • Interior courtesy lighting

Options
