2020 Party Barge 22 RF DLX

2020

PARTY BARGE® 22 RF DLX

w/ 60 ELPT FourStroke Command Thrust Mercury® FourStroke
Price Excludes Optional Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
Base Price
$25595
USD

Overview

The “RF” in its name stands for “rear facing,” which means the PARTY BARGE® 22 RF DLX replaces the aft port couch with a double-wide, rear-facing lounge—the perfect spot for relaxing with close friends and family members.

This boat offers so much more just that super-comfortable, perfectly positioned lounging spot, though! There are three other couches throughout, all with the STOW MORE™ seat storage system, which combines underseat and seat-back compartments to provide huge amounts of space. It also offers a new Bazooka® sound system, new 11’ Bimini top (complete with QUICKLIFT® deployment system), cooler storage, a swim platform and a fold-down boarding ladder!

It’s everything you need to relax how you want all summer long.

Key Features

Aft lounge

The rear-facing (RF) lounge is double wide so two can lie back and watch the perfect sunset.

Changing curtain

Flip up the aft lounge to deploy the standard changing curtain—perfect to donning swimwear!

Bow platform

The bow platform is wide enough for sitting on with your feet in the water, or even laying towels on to dry.


Videos


Specifications

Length 7.37 m 24' 2''
Deck length 6.73 m 22' 1''
Deck Width 2.59 m 8' 6''
Max. Recommended HP 150 HP
Fuel Capacity 121.5 L 32.1 gal.
Pontoon log length 6.78 m 22' 3''
Pontoon log diameter 60.96 cm 24''
Pontoon log material 0.080 5052 marine alloy
Max. Person Capacity 11 persons
Max. person weight 680.39 kg 1500 lbs.
Max. person, motor & gear weight 997.9 kg 2200 lbs.
Interior depth 74.93 cm 29.5''
Average dry weight 1042.81 kg 2299 lbs.
Average package weight 1874.7 kg 4133 lbs.
Package height 2.69 m 8' 10''
Package width 2.59 m 8' 6''
Towing length 9.86 m 32' 4''
Storage Length 9.86 m 32' 4''

Motor Options

AVAILABLE MOTOR ESTIMATED SPEEDS PACKAGE PRICE VIEW PRICE W/ PREP & FREIGHT
Mercury® FourStroke
9.9 ELPT FourStroke Command Thrust ProKicker -
$21075

USD
Select Dealer
25 ELPT FourStroke -
$22895

USD
Select Dealer
60 ELPT FourStroke Command Thrust -
$25595

USD
Select Dealer
90 ELPT FourStroke Command Thrust 23-29 mph
$27695

USD
Select Dealer
115 ELPT FourStroke Command Thrust 23-33 mph
$28695

USD
Select Dealer
150 L FourStroke 29-38 mph
$31095

USD
Select Dealer
Mercury® Pro XS®
115 ELPT Pro XS® FourStroke Command Thrust -
$29055

USD
Select Dealer

Features

Comfort, Convenience & Peace of Mind
  • 10+LIFE™ Limited Lifetime Warranty
  • NMMA® certified
  • NEW 11' (3.35 m) color-keyed Bimini top w/LED courtesy lights, protective boot & accepts optional drop-down changing curtain
  • NEW Bazooka® Party Bar stereo & speakers in the Bimini top
  • Front zipper on Bimini top to join optional forward Bimini together
  • QUICKLIFT® Bimini top deployment system, allowing 1 person to effortlessly extend the canopy alone
  • Storage pockets in Bimini top
  • Nylon gate latches & heavy-duty hinges that open inward
  • Port & starboard LED navigation lights
  • Bimini-mounted anchor/navigation light
  • 4 folding mooring cleats
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn
Console
  • Deluxe soft-touch sport steering wheel
  • 4:2 ratio no-feedback steering for responsive, easy turning
  • Wraparound sport shroud & tinted, removable windscreen
  • Below-console cooler/storage space w/door & integrated pouch
  • Small items tray
  • Drink holders
  • Built-in footrest w/non-skid pad
  • Bluetooth®-capable stereo interface for Bazooka® Party Bar
  • Tachometer, trim meter/speedometer & fuel & hour gauges
  • Lighted rocker switches
  • Ergonomically positioned Mercury® binnacle control box w/trim
  • 12V outlet
  • NEW darker console color
Interior
  • STOW MORE™ system features an added compartment in the seat back for increased storage
  • Bow port & starboard couches w/STOW MORE™ system & underseat storage
  • Midship port L-lounge w/STOW MORE™ system & underseat storage
  • Aft port rear-facing double lounge w/STOW MORE™ system, underseat storage & pop-up changing room
  • Aft starboard couch w/STOW MORE™ system & lockable underseat storage
  • High-back swiveling helm bucket seat, reclining & w/self-leveling arms
  • Full-width aft swim deck
  • Woven 16-oz. (.45 kg) marine-grade flooring throughout
  • NEW marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam
  • 2 movable drink holders/armrests
  • Removable table w/padded insert, 4 molded-in drink holders & 2 pedestal base locations
  • Port wheelchair-access gate
  • 4-step folding boarding ladder w/grab rails
Performance
  • Nose cone & motor pod wave/spray deflectors for a drier ride
  • Factory-matched aluminum propeller
Construction & Exterior
  • Color: Black Metallic or Caribou Metallic fencing
  • NEW exterior styling
  • Plasma & laser cutters & robotic welding help ensure precise fit & finish throughout
  • Heavy-duty bow U-channel reinforcement behind deck trim
  • 24" (60.96 cm) diameter high-buoyancy multichambered pontoons w/internal bracing for additional strength
  • 1-piece full-length M-bracket deck supports
  • RAIL-LOCK® system for mounting optional tops & optional mooring cover
  • NEW protective exoskeleton rail & panel system for durability & a quieter ride
  • High-sheen fence finish for long-lasting good looks
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails w/NEW decorative styling & taller mid-rail fencing height
  • Reinforced bow structure
  • Extruded anodized aluminum deck edging w/polished aft corner covers
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • Stainless or coated corrosion-resistant fasteners
  • 7-ply pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • Full-width heavy-duty extruded Z-bar deck supports that are thru-bolted to M-brackets
  • Elevated fence panels for deck drainage & ventilation
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Box-beam all-aluminum transom for strength & longevity
Electrical
  • Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
  • Interior courtesy lighting

Options


Gallery

Purchase your Sun Tracker and take delivery through your nearest dealer!

Uncompromising Versatility

To view price with dealer prep and freight, use the search box to locate and choose a dealer near you.
