Build Information

• Custom Colors
• Specifications
  Standard|Metric

  Length	24' 2''	7.37 m
  Deck Length	22' 1''	6.73 m
  Deck Width	8' 6''	2.59 m
  Max. Recommended HP	150 HP
  Fuel Capacity	32.1 gal.	121.5 L
  Pontoon Log Length	22' 3''	6.78 m
  Pontoon Log Diameter	24''	60.96 cm
  Pontoon Log Material	0.080 5052 marine alloy
  Max. Person Capacity	11 persons
  Max. Person Weight	1500 lbs.	680.39 kg
  Max. Person, Motor & Gear Weight	2200 lbs.	997.9 kg
  Interior Depth	29.5''	74.93 cm
  Average Dry Weight	2080 lbs.	943.47 kg
  Average Package Weight	3915 lbs.	1775.81 kg
  Package Height	8' 10''	2.69 m
  Package Width	8' 6''	2.59 m
  Towing Length	32' 4''	9.86 m
  Storage Length	32' 4''	9.86 m

• Model Features
  Comfort, Convenience & Peace of Mind

  • 10+LIFE™ Limited Lifetime Warranty: 10-year bow-to-stern warranty + limited lifetime structural & deck warranty
  • NMMA® certified
  • 10' (3.05 m) SUN TRACKER® QuickLift™ Bimini top w/LED courtesy lights, storage pockets & protective boot (color-coordinated Black w/Charcoal fencing or Sand w/Copper Red fencing)
  • Built-in LED docking lights
  • Built-in LED navigation & anchor lights
  • 4 folding mooring cleats & starboard side tie-off mooring eye
  • Port wheelchair-accessible gate
  • Rear boarding platform w/4-step telescoping boarding ladder & grab rails
  • Aft receptacle base for optional ski tow pylon
  • Motor-stop safety lanyard
  • Fire extinguisher
  • Horn

  Console

  • Driver console w/integrated storage, drink holders, built-in footrest & ergonomically-positioned controls
  • SUN TRACKER FLARE™ touchscreen gauge display & 12-button switch panel
  • Tilt steering w/deluxe soft-touch steering wheel
  • Wet Sounds® stereo w/Bluetooth® & four 6.5" (16.51 cm) speakers, strategically located & shielded within the seat bases
  • Master power on/off switch
  • Recessed mobile phone cubbies
  • USB charging receptacle

  Interior

  • Patented built-in STOW MORE™ seat-back storage system for all couches
  • Bow port couch w/STOW MORE™, underseat storage & armrest w/drink holder
  • Bow starboard console couch w/STOW MORE™ & underseat storage
  • 2 movable drink holders/armrests for couch seating
  • Midship port side drink holder
  • Removable table w/soft-touch insert; 4 molded-in drink holders; & 2 pedestal base locations
  • Reclining, high-back swiveling port & helm bucket seats w/self-leveling armrests
  • Aft port couch w/STOW MORE™ & underseat storage
  • Aft starboard couch w/STOW MORE™ & underseat, lockable storage
  • Interior courtesy lighting
  • Full-width aft swim deck
  • Woven 16-oz. (.45 kg) marine-grade flooring throughout
  • Marine-grade, UV-resistant, top-coated upholstery w/26-oz. (.74 kg) base material & multiple densities of foam

  Performance

  • 24" (60.96 cm) diameter high-buoyancy multichambered & internally-braced pontoon logs
  • Full-length, 1-piece longitudinal M-bracket deck supports
  • Full-width, heavy-duty extruded Z-bar deck supports that are thru-bolted to longitudinal M-brackets
  • Heavy-duty aluminum U-channel reinforcement behind bow deck trim
  • Reinforced bow structure
  • All-welded, all-aluminum extended motor pod w/built-in EPA-compliant fuel system
  • All-aluminum box-beam transom for strength & longevity
  • Pressure-treated 3/4" (1.91 cm) deck w/Limited Lifetime Warranty
  • 1-1/4" (3.18 cm), .090" (.23 cm) thick anodized aluminum fence rails
  • Sound- & vibration-deadening fence insulation for a quiet ride
  • Extruded & anodized aluminum deck edging w/polished aft corner covers
  • Precision fit & finish via plasma & laser-cut parts & robotically-welded construction
  • Rotomolded storage, furniture & console for superior strength & longevity
  • Nylon gate latches & heavy-duty hinges that open inward
  • Stainless or coated corrosion-resistant fasteners
  • Factory-matched aluminum propeller

  Exterior

  • Color: Charcoal or Copper Red fencing
  • Patent-pending TRACK FORMED® fence design w/high-sheen finish for long-lasting cosmetics
  • Elevated fence panels for deck drainage & ventilation

  Electrical

  • Easy-access marine-grade automotive-style fuse panel w/latching fuse block door
  • Protective abrasion-resistant wire wrap
  • Water-resistant connectors
